The Gateron Double-Rail Magnetic Switch in the "Dawn" variant with 110 switches is a high-end switch for users seeking maximum precision, stability, and durability in their keyboard setup. Equipped with Hall-effect technology instead of conventional metal contacts, it enables extremely precise actuation points and long-lasting performance. The dual-rail design significantly reduces lateral play ("wobble"), and factory lubrication ensures an instantly smooth typing experience—ideal for high-end builds and gaming setups.

Technical specifications:

• Type: Linear (no click, no tactile feedback)

• Technology: Hall effect (magnetic sensor technology)

• Actuating force (initial): approx. 30 gf

• Bottom-out force: approx. 50 gf

• Total Travel: approx. 4.0 mm

• Adjustable trigger point: from approx. 0.5 mm to approx. 3.8 mm

• Sensitivity of the magnetic sensor: approx. 0.1 mm

• Stem material: POM (polyoxymethylene)

• Housing materials: Top housing transparent (PC), bottom housing nylon, etc.

• Lifespan: up to approximately 150 million actuations

• Package: 110 pieces

• Note: Only compatible with PCBs that support Hall effect/magnetic switches.
