The Búri Diamond Switch is a high-quality linear switch specifically designed for custom keyboard builders who appreciate smooth key feel and elegant aesthetics. Featuring a transparent housing, POM stem, and extended spring mechanism, it stands out for its smooth action, good light transmission, and solid construction. Ideal for builds that prioritize both style and performance.

Technical specifications

• Design: Linear (without a perceptible bump or click)

• Operating force: approx. 45 gf

• Pre-travel (time before shutter release): approx. 1.9 mm

• Total Travel: approx. 3.8 mm

• Bottom-out force: approx. 55 gf

• Stem material: POM

• Housing material: Top and bottom of the house made of nylon or nylon blend

• Spring length: approx. 21.5 mm (long spring)

• Lifespan: designed for approximately 80 million keystrokes

• Mounting form: PCB mount, 5-pin (MX footprint)

• Lubrication: Lightly lubricated on the lightweight side
